4.4 LOAD PRESET

A preset can be loaded from the following menu pages:

Table 7: LOAD PRESET pages

Page

Memory range

Contents

LOAD PRESET USER

1 – 10 (read and write)

User presets stored by the user (see section 4.5).

LOAD PRESET FACTORY

11 – 199 (read only)

Factory preset library created by L-ACOUSTICS

and

automatically installed during firmware update (refer to

the LA NETWORK MANAGER video tutorial).

To load a preset, follow these steps (see also Figure 26):

From the main menu, select LOAD PRESET USER or LOAD PRESET FACTORY. 1.

If the controller displays NO PRESETS AVAILABLE! when you select LOAD PRESET USER, it means that all user

memories are empty. Press the ESC key to abort. — END —

Else, continue the procedure.

Turn the encoder wheel to scroll through the presets.

Press the OK key or the encoder wheel to select a preset (or ESC to abort). 3.

The controller displays ARE YOU SURE?.

Press the OK key or the encoder wheel to validate (or ESC to abort). 4.

If the controller displays the main screen, it means that the preset has been successfully loaded. — END —

If the controller displays CLEAR GROUP PARAM? OUTPUTS MUTED!, it means that it has been assigned to

groups (see section 4.3.1, group information) and that it is no longer connected to L-NET (see section 4.2.3).

Press the OK key to load the preset while clearing the group parameters, or press the ESC key to load the

preset while keeping the group parameters active. — END —

If the controller displays GROUP CONFLICT! CLEAR GROUP PARAM?, it means that its output channels have

been assigned to groups (see section 4.3.1, group information) and that the assignation structure is not

compatible with the channel sets of the preset to load (see section 4.7). Thus, loading the preset is only

possible if the group parameters are cleared.

Press the OK key to load the preset while clearing the group parameters, or press the ESC key two times to

abort. — END —

If the controller displays GROUP CONFLICT! CANNOT LOAD PRESET, it means that its output channels have

been assigned to groups (see section 4.3.1, group information) and that the assignation structure is not

compatible with the channel sets of the preset to load (see section 4.7). Moreover, as it is connected to L-

NET (see section 4.2.3), it is not possible to cancel the group parameters to allow loading the preset.

Press the ESC key to abort. — END —
