APPENDIX C 5XT SPECIFICATIONS

Description

2-way passive coaxial enclosure, amplified by LA4 or LA8

Usable bandwidth (-10 dB)

95 Hz – 20 kHz ([5XT] preset)

Maximum SPL

119 dB ([5XT] preset)

Coverage angle (-6 dB)

110° axi-symmetric

Transducers

LF: 1 × 5” weather resistant, bass-reflex

HF: 1 × 1” diaphragm compression driver

Nominal impedance

16 Ω

RMS power handling

85 W ([5XT] preset)

Connectors

IN: 1 × 4-point SpeakON

IN/LINK: 2 × screw terminals

LINK: 1 × 4-point SpeakON

Dimensions

Rigging components

1 × 3/8” insert for microphone stand

2 × M6 inserts for ETR5 U-bracket

Physical data

Weight (net):

3.5 kg / 7.7 lb

Cabinet:

baltic birch plywood

Finish:

Grayish Brown RAL 8019

or Pure White RAL 9010

Custom finish:

RAL code on special order

Rigging components and grill:

steel with anti-corrosion coating

Peak level at 1 m under free field conditions using 10 dB crest factor pink noise with specified preset.
