5XT_UM_EN_1.0 w w w . l - a c o u s t i c s . c o m 5
2 SYSTEM COMPONENTS
The system approach developed by L-ACOUSTICS
®
consists in offering a global solution that guarantees the highest
and most predictable level of performance at any step of loudspeaker system deployment: modeling, installation and
operation. A complete L-ACOUSTICS
®
system includes enclosures, amplified controllers, cables, rigging system and
software applications.
2.1 Loudspeaker enclosures
5XT
Full-range enclosure (95 Hz – 20 kHz), 2-way passive, coaxial.
SB15m
High power compact subwoofer (down to 40 Hz).
Loudspeaker system design
Sound design aspects are beyond the scope of this document. However, the various applications of the
system will be based on the operating modes presented in this document.
2.2 Powering and driving system
LA4 or LA8
Amplified controller with DSP, preset library and networking capabilities.
Operating instructions
Refer to the LA4 and LA8 user manual.
2.3 Loudspeaker cables
8-point PA-COM
®
loudspeaker cables
respective lengths of 0.7 m/2.3 ft, 10 m/32.8 ft, and 25 m/82 ft.
Breakout cable for four passive enclosures.
One PA-COM
®
to 4 4-point SpeakON
®
.
4-point SpeakON
®
loudspeaker cables.
Respective lengths of 0.7 m/2.3 ft, 5 m/16.4 ft, 10 m/32.8 ft and 25 m/82 ft.
2-point cable with a SpeakON
®
connector at one end and two wires at the other
(1+ and 1-).
This cable is not provided and needs to be custom made.
2.5 mm² cable used to connect 5XT enclosures in parallel for fixed installation.
Breakout cable for two passive enclosures with CC4FP adapter.
One 4-point SpeakON
®
to 2 2-point SpeakON
®
.
Information about the connection of the enclosures to the LA amplifiers is given in this document.
Refer to the LA4 and LA8 user manuals for detailed instructions about the whole cabling scheme, including
modulation cables and network.
2.4 Rigging element
Rigging elements or procedures are not presented in this document.
Refer to the 5XT rigging manual.
2.5 Software application
SOUNDVISION
Proprietary acoustical and mechanical 3D modeling software.
LA NETWORK MANAGER
Remote control and monitoring of amplified controllers
Using L-ACOUSTICS
®
software
Refer to the SOUNDVISION user manual and the LA NETWORK MANAGER tutorial.
