Behringer B205D EUROLIVE [10/13] Specifications especificaciones técnicas
![Behringer B205D EUROLIVE [10/13] Specifications especificaciones técnicas](/views2/2008137/page10/bga.png)
18 EUROLIVE B205D
19
Quick Start Guide
Specications Especicaciones técnicas
Amplier Power Output
RMS power 125 Watts @ 6 Ω
Peak power 150 Watts @ 6 Ω
Speaker Size
Size 5.25" / 133.5 mm
Audio Inputs
Channel 1: XLR / ¼" TRS combo jacks
Sensitivity -40 dBu to +4 dBu
Input impedance 20 kΩ / 1 MΩ switchable
Channel 2: XLR / ¼" TRS combo jacks
Sensitivity -40 dBu to +4 dBu
Input impedance 20 kΩ
Channel 3: RCA jacks
Sensitivity -10 dBu to +4 dBu
Input impedance 10 kΩ
Phantom power
Channels 2 and 3 +48 Volts, switchable
Channel level controls
Input Trim –∞ to + 30 dB
Max. input level +22 dBu
Link
Thru XLR connector, mic/line switchable
Main in XLR / ¼" TRS combo jack
Loudspeaker System Data
Frequency response 65 Hz to 18 kHz (-10 dB)
95 Hz to 12 kHz (-3 dB)
Sound pressure level max. 113 dB SPL @ 1 m
Limiter Optical
Dynamic equalizer Processor-controlled
Equalizer
HIGH 12 kHz / ±15 dB
MID 2.5 kHz / ±15 dB
LOW 100 Hz / ±15 dB
Power Supply
Voltage (Fuses)
USA/Canada 120 V~, 60 Hz (T 3.15 A H 250 V)
UK/Australia 240 V~, 50 Hz (T 3.15 A H 250 V)
Europe 230 V~, 50 Hz (T 3.15 A H 250 V)
Japan 100 V~, 50/60 Hz (T 3.15 A H 250 V)
Power consumption max. 180 Watts
Mains connection Standard IEC receptacle
Dimensions/Weight
Dimensions (H x W x D) 7.30 x 11.42 x 8.70" / 185 x 290 x 220 mm
Weight 7.0 lbs / 3.20 kg
Salida de Alimentación del Amplicador
Alimentación RMS 125 vatios a 6 Ω
Potencia máxima 150 vatios a 6 Ω
Tamaño del Altavoz
Tamaño 5,25 x 5,25" / 133,5 x 133,5 mm
Entradas de Audio
Canal 1: toma combinada XLR / TRS de ¼"
Sensibilidad -40 dBu a +4 dBu
Impedancia de entrada 20 kΩ / 1 MΩ conmutable
Canal 2: toma combinada XLR / TRS de ¼"
Sensibilidad -40 dBu a +4 dBu
Impedancia de entrada 20 kΩ
Canal 3: tomas RCA
Sensibilidad -10 dBu a +4 dBu
Impedancia de entrada 10 kΩ
Alimentación phantom: canales 2 y 3 +48 voltios, conmutable
Controles de nivel de canal
Compensación de entrada –∞ a + 30 dB
Nivel de entrada máx. +22 dBu
Conexión
THRU Conector XLR, MIC/LINE conmutable
MAIN IN Toma combinada XLR / TRS de ¼"
Datos del Sistema de Altavoces
Respuesta de frecuencia 65 Hz hasta 18 kHz (-10 dB)
95 Hz hasta 12 kHz (-3 dB)
Nivel de presión de sonido Máx. 113 dB SPL a 1 m
Limitador Óptico
Ecualizador dinámico Controlado por procesador
Ecualizador
HIGH 12 kHz / ±15 dB
MID 2,5 kHz / ±15 dB
LOW 100 kHz / ±15 dB
Fuente de Alimentación
Voltaje (fusibles)
EE. UU./Canadá 120 V~, 60 Hz (T 3,15 A H 250 V)
RU/Australia 240 V~, 50 Hz (T 3,15 A H 250 V)
Europa 230 V~, 50 Hz (T 3,15 A H 250 V)
Japón 100 V~, 50/60 Hz (T 3,15 A H 250 V)
Consumo de energía Máx. 180 vatios
Conexión a la red eléctrica Conector IEC estándar
Dimensiones/Peso
Dimensiones (alto x ancho x profundo) 7,30 x 11,42 x 8,70" / 185 x 290 x 220 mm
Peso 7,0 libras / 3,20 kg
