©American DJ® - www.americandj.com - Spherion Tri LED Instruction Manual Page 11
have found your desired color press ENTER.
3. Press the UP or DOWN button so that “ROTA” is displayed. In
this setting you can control rotation. Press the ENTER button,
“XXX” will be displayed. “XXX” representing a number between
0-255.
0-9 is no rotation, 10-113 is clockwise rotation fast-slow,
114-141 is no rotation, 142-245 is counter-clockwise rotation
slow-fast, and 248-255 is no rotation.
4. Adjust the rotation as you desire, then press ENTER.
SOUN - Sound Active mode.
1. Press the MENU button until “SOUN” is displayed, press
ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to activate sound active mode, or
“OFF” to deactivate sound active mode.
3. Press the ENTER, and then press and hold the MENU button
for at least 3 seconds to conrm.
SENS - Sound sensitivity control.
1. Press the MENU button until “SENS” is displayed, press
ENTER.
2. The display will show a number between 0-100. Press the UP
or DOWN buttons to adjust the sound sensitivity. 0 being the
least sensitive and 100 the most sensitive.
3. Press the ENTER, and then press and hold the MENU button
for at least 3 seconds to conrm.
BLND - Blackout or Stand by mode.
1. Press the MENU button until “BLND” is displayed, press
Spherion Tri LED System Menu
ENTER. Either Yes or No will be displayed.
2. To activate Blackout tap the UP or DOWN buttons until “Yes”
is displayed, press ENTER to conm. The xture will now be in
Blackout mode. To deactivate Blackout mode, select “No” and
press Enter.
LED - With this function you can have the LED display turn
off after 10 seconds.
1. Press the MENU button until “LED” is displayed, press
ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to keep the LED display on at
all times, or “OFF” to switch to have the LED display switch off
after 10 seconds.
3. Press ENTER to conrm.
DISP - This will “ip” the LED display 180º.
1. Press the MENU button until “dISP” is displayed, press
ENTER.
2. Either “dISP” or “dSIP” will now be displayed. Press the UP or
DOWN buttons to select one or the other.
3. Press the ENTER, and then press and hold the MENU button
for at least 3 seconds to conrm.
TEST - This function will run a self test program.
1. Press the MENU button until “TEST” is displayed, press
ENTER.
2. The xture will now run a self test.
FHRS - With this function you can display the running time
Spherion Tri LED System Menu
©American DJ® - www.americandj.com - Spherion Tri LED Instruction Manual Page 12
