Spherion Tri LED System Menu Spherion Tri LED System Menu

Operating Modes: The Spherion Tri LED can operate in four

different modes. In each mode you can run the fixture as a

stand alone fixture or in a master/slave confiugration. This next

section will detail the differences in the operating modes.

• Sound Active mode -

The fixture will react to sound.

with a standard DMX-512 controller such as the Elation® Show

Designer.

™

System Menu: When making adjustments you can press

ENTER to conrm your setup or you can wait 8 seconds for

automatic setup. To exit without making any adjustments

press the MENU button.

ADDR - DMX Address Setting. See page 14 for more infor-

mation on DMX Control.

1. Press the either the MENU, UP, or DOWN buttons until

press ENTER. Either “1CH” or “3CH” will be displayed

2. Press the UP or DOWN buttons to choose your desired DMX

mode and press ENTER to conm and exit.

SLND - This will let you set unit as a master or slave in a

master/slave conguration.

1. Press the MENU button until “SLND” is displayed, press

ENTER. Either “MAST”,“SL 1” or “SL 2” will be displayed.

2. Press the UP or DOWN buttons until your desired setting is

displayed, press ENTER to conm.

NOTE: In a Master/Slave conguration you can set one xture

1. Press the MENU button until “SHND” is displayed, press

ENTER.

2. “Sh X” will now be displayed, “X” representing a number

between 0-7. Programs 0-7 are factory programs, while “Sh 0”

is random mode. Press the UP or DOWN buttons to nd your

desired show and press the ENTER, then press and hold the

MENU button for at least 3 seconds to conrm.

Note: While running a Show, you can change the show instantly

by pressing the UP or DOWN buttons.

PROG - In this mode you can choose 1 of 7 colors and con-
