AMERICAN DJ Spherion TRI LED [7/10] Master slave operation
![AMERICAN DJ Spherion TRI LED [7/10] Master slave operation](/views2/2008149/page7/bg7.png)
Universal DMX Control: This function allows you to use a Elation®
universal DMX-512 controller to control the chases and patterns,
dimmer and strobe. A DMX controller allows you to create unique
programs tailored to your individual needs.
1. The Spherion Tri LED can be either a 1 or 3 DMX channel fixture.
See page 15 for detailed description of the DMX values and
traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 6-8 as well as the set-up specifications that are includ-
ed with your DMX controller.
3. Use the controller’s faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instructions on page 9 to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Spherion Tri LED DMX Control
©American DJ® - www.americandj.com - Spherion Tri LED Instruction Manual Page 13 ©American DJ® - www.americandj.com - Spherion Tri LED Instruction Manual Page 14
Spherion Tri LED System Menu
of the xture.
1. Press the MENU button until “FHRS” is displayed, press
ENTER.
2. The running time of the xture will now be displayed. Press
MENU to exit.
VER - With this function you can display the version soft-
ware of the xture.
1. Press the MENU button until “VER” is displayed, press
ENTER.
2. The software version will now be displayed. Press MENU to
exit
RSET - Use this function to reset the unit.
1. Press the MENU button until “RSET” is displayed, press
ENTER.
2. The xture will now reset
Master-Slave Operation This function will allow you to link up to 16
units together and operate without a controller. The units will be sound
activated. In Master-Slave operation one unit will act as the controlling
unit and the others will react to the controlling units programs. Any unit
can act as a Master or as a Slave.
1. Using approved DMX data cables, daisy chain your units togeth-
er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector
is the output. The rst unit in the chain (master) will use the female
XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-
tor at the last fixture.
2. On the Master unit find and run your desired operating mode.
3. On the slave units tap the MENU button until “SLND” is dis-
played, and Press ENTER. See page 9 under “SLND” for more
infomation.
4. The slave units will now follow the Master unit.
Spherion Tri LED Master-Slave Configuration
