Spherion Tri LED Fuse Replacement
Disconnect the unit’s main power supply. Insert a standard flat head
screw driver in to the fuse holder housing. Turn the screwdriver in
counter-clockwise direction to remove the fuse holder. Remove the
old fuse and discard it, replace the fuse with the same type. Insert
the fuse holder back into it’s housing and turn in clockwise direction
to lock the holder in place.
Spherion Tri LED Cleaning
Fixture Cleaning: Due to fog residue, smoke, and dust cleaning the
internal and external optical lenses and mirror should be carried out
periodically to optimize light output. Cleaning frequency depends on
the environment in which the fixture operates (I.e. smoke, fog residue,
dust, dew). In heavy club use we recommend cleaning on a monthly
basis. Periodic cleaning will ensure longevity, and crisp output.
1. Use normal glass cleaner and a soft cloth to wipe down the out-
side casing.
2. Use a brush to wipe down the cooling vents and fan grill.
3. Clean the external optics with glass cleaner and a soft cloth every
20 days.
4. Clean the internal optics with glass cleaner and a soft cloth every
30-60 days.
5. Always be sure to dry all parts completely before plugging the unit
back in.
Spherion Tri LED 1 DMX Channel Mode - DMX Traits
Channel Value Function
1 SHOWS
0 - 7 BLACKOUT
8 - 47 SHOW 1
48 - 87 SHOW 2
88 - 127 SHOW 3
128 - 167 SHOW 4
168 - 207 SHOW 5
208 - 247 SHOW 6
248 - 255 SOUND ACTIVE
Spherion Tri LED UC3 Control
Blackout Blackout the unit
Function
1. Synchronous Strobe in white
2. Asynchronous Strobe in whtie
3. Sound Strobe in color
Select color
1. Red
2. Green
3. Blue
4. Red+Green
5. Green+Blue
6. Red+Blue
7. Red+Green+Blue
8. Color change by sound
Select
Show(1-7)
Mode
Sound
(LED OFF)
Manual Color
(LED ON)
Show(LED
slow
blinking)
Channel Value Function
1 ROTATION
0 - 9 STOP
10 - 113 CLOCKWISE ROTATION FAST-SLOW
114 - 141 STOP
142 - 245 COUNTER-CLOCKWISE ROTATION
FAST - SLOW
246 - 247 STOP
248 - 255 SOUND ACTIVE
2 DIMMER & STROBE
0 - 7 OFF
8 - 199 DIMMER 0% - 100%
200 - 247 STROBING FAST - SLOW
248 - 255 ON
3 COLOR
0 - 46 COLOR 1
47 - 85 COLOR 2
86 - 124 COLOR 3
125 - 163 COLOR 4
164 - 202 COLOR 5
203 - 240 COLOR 6
241 - 255 COLOR 7
Spherion Tri LED 3 DMX Channel Mode - DMX Traits
©American DJ® - www.americandj.com - Spherion Tri LED Instruction Manual Page 15 ©American DJ® - www.americandj.com - Spherion Tri LED Instruction Manual Page 16
