Preampliﬁers

light up when the signal is at its highest level. MIC B has its

own lo and hi tone controls. MIC B input is compatible with the

Apart ALINP local input panel that requires phantom voltage.

Note:When you only use the RCA inputs, keep the mic/line

select switch set to “LINE” to improve the output noise.

4. Input 1-4: line level input on RCA connectors. Adjust the gain

control so that the clip led does not light up when the signal is

at its highest level.

5. Zone 1 EQ: lo and hi tone controls for the selected line input

1-4 being fed to zone 1 output.

6. Zone 1 out:

a. Mono/stereo switch: With this switch the output can be

conﬁgured as a mono output or stereo output.

b. Balanced / RCA outputs: Balanced and RCA output supply a

line level output signal.

7. Zone 2 EQ: lo and hi tone controls for the selected line input

1-4 being fed to zone 2 output.

8. Zone 2 out:

a. Mono/stereo switch: with this switch the output can be

conﬁgured as a mono output or stereo output.

b. Balanced / RCA outputs: balanced and RCA output supply a

line level output signal.

9. Main power input, switch and fuse: connect the mains power

cord here. Switch on the power switch to power up the unit.

The mains fuse is also located here.
