Instruction manualPREZONE1

1. On/Standby button and led: switch the standby ON/OFF with this

button. Please note that the main power switch at the rear of the

unit must be switched on. Read more about the standby below.

When the unit is on, the on/standby button led will light up steadily.

When the unit is in standby, the led will fade in/ fade out.

2. MIC A/B volume control: this control determines the output volume

of MIC A/B for both zones.

3. MIC A/B on/off switch: use this button to turn MIC A/B on and off

for both zones.

4. Name ﬁeld: here you can attach the name stickers and the name

ﬁelds supplied with the unit.

5. Input 1 – 4 selection buttons: by pressing these buttons, you can

toggle between inputs 1 to 4, or switch off the selected input by

pressing the button that is lit. You can only select one input at a

time for both zones.

6. Zone 1 on/off button and volume control: By pressing the on/off

button, the zone can be enabled (green) or disabled (red). While

the zone is muted, the selected inputs will be muted in these zones.

Operation
