12 VIRTUAL AMPLIFICATION V-AMP 3 User Manual
Cabinets
— BYPASS (NO SPEAKER SIMULATION)
1 1 x 8" VINTAGE TWEED
2 4 x 10" VINTAGE BASS
3 4 x 10" V-AMP CUSTOM
4 1 x 12" MID COMBO
5 1 x 12" BLACKFACE
6 1 x 12" BRIT '60
7 1 x 12" DELUXE '52
8 2 x 12" TWIN COMBO
9 2 x 12" US CLASS A
10 2 x 12" V-AMP CUSTOM
11 2 x 12" BRIT '67
12 4 x 12" VINTAGE 30
13 4 x 12" STANDARD '78
14 4 x 12" OFF AXIS
15 4 x 12" V-AMP CUSTOM
AMPS 1-16 Category Speaker simulation Cabinet #
TUBE PRE Clean — —
CLASSIC CLEAN Clean 2 x 12" TWIN COMBO 8
CLEAN V-AMP Clean 4 x 12" V-AMP CUSTOM 15
BLACK TWIN Clean 2 x 12" TWIN COMBO 8
AMERICAN Blues 4 x 10" VINTAGE BASS 2
DELUXE BLUES Blues 1 x 12" BLACKFACE 5
BRIT BLUES Blues 4 x 12" VINTAGE 30 12
CUSTOM BLUES Blues 4 x 12" VINTAGE 30 12
NUMETAL GAIN Metal 4 x 12" V-AMP CUSTOM 15
SAVAGE BEAST Metal 4 x 12" V-AMP CUSTOM 15
BRIT HI GAIN Metal 4 x 12" VINTAGE 30 12
ULTRAZONIC Metal 4 x 12" V-AMP CUSTOM 15
ROCK 59SL Rock 4 x 12" V-AMP CUSTOM 15
HIBRIT 100 Rock 4 x 12" V-AMP CUSTOM 15
AMBER 120 Rock 4 x 12" VINTAGE 30 12
BRIT CLASSIC Rock 4 x 12" V-AMP CUSTOM 15
SMALL COMBO Clean 1 x 8" VINTAGE TWEED 1
TWEED COMBO Clean 1 x 8" VINTAGE TWEED 1
CALIF CLEAN Clean 4 x 12" V-AMP CUSTOM 15
CUSTOM CLEAN Clean 1 x 12" BLACKFACE 5
FUZZ BOX Rock 4 x 12" OFF AXIS 14
V-AMP DRIVE Rock 4 x 12" V-AMP CUSTOM 15
V-CRUNCH Rock 4 x 12" V-AMP CUSTOM 15
BRIT CLASSIC 50 W Rock 2 x 12" V-AMP CUSTOM 10
NUMETAL HD Metal 4 x 12" V-AMP CUSTOM 15
CUSTOM HI GAIN Metal 4 x 12" V-AMP CUSTOM 15
MODERN HI GAIN Metal 4 x 12" V-AMP CUSTOM 15
ULTIMATE PLUS Metal 4 x 12" V-AMP CUSTOM 15
BRIT CLASS A Rock 2 x 12" BRIT '67 11
CUSTOM CLASS A Rock 4 x 12" VINTAGE 30 12
CLASS A NORM Rock 2 x 12" BRIT '67 11
BRIT CLASS A 15 W Rock 1 x 12" BRIT '60 6
Eects Processor
A great complement to the selection of amps and speaker cabinets is the
built-in multi-eects processor. You may select from 16 high-quality eects
such as chorus, anger, delay, auto wah, and many others. These eects can
be used to thicken up your guitar tone in a subtle way, or create extreme and
experimental sounds that push your creative limits. The standard operating
mode of the multi-eects processor is stereo, but other options are available
(see Congurations section).
You can adjust up to 3 parameters for each available eect. Two of these
parameters are adjusted using the EFFECTS knob with or without the TAP button
held down. Tempo-based parameters are adjusted by pressing the TAP button
at least twice in sync with the music. The following table displays the parameter
controls for each eect.
Eect # Eect
EFFECT
Control
EFFECTS
control with TAP
push button
TAP push button
1 ECHO CC49, val 1 Mix CC54 Feedback CC53 Delay Time CC50+51
2 DELAY CC49, val 0 Mix CC54 Feedback CC53 Delay Time CC50+51
3
PING PONG
CC49, val 2
Mix CC54 Feedback CC53 Delay Time CC50+51
4
PHASER/DELAY
CC55, val 1 +
CC49, val 0
Delay Mix
CC54
Mod. Mix CC59 Delay Time CC50+51
5
FLANGER/DELAY
1 CC55, val 5 +
CC49, val 0
Delay Mix
CC54
Mod. Mix CC59 Delay Time CC50+51
6
FLANGER/ DELAY
2 CC55, val 5 +
CC49, val 2
Delay Mix
CC54
Mod. Mix CC59 Delay Time CC50+51
7
CHORUS/ DELAY
1 CC55, val 3 +
CC49, val 0
Delay Mix
CC54
Mod. Mix CC59 Delay Time CC50+51
8
CHORUS/ DELAY
2 CC55, val 3 +
CC49, val 2
Delay Mix
CC54
Mod. Mix CC59 Delay Time CC50+51
9
CHORUS/
COMPRESSOR
CC55, val 4 +
CC44, val 1
Sense CC45 Mod. Mix CC59
Modulation Speed
CC58
10
COMPRESSOR
CC44, val 1
Sense CC45 Attack CC46 —
11
AUTO WAH
CC44, val 2
Depth CC45 Speed CC46 —
12
PHASER
CC55, val 1
Mix CC59 Feedback CC58
Modulation Speed
CC56
13
CHORUS
CC55, val 4
Mix CC59 Depth CC57
Modulation Speed
CC56
14
FLANGER
CC55, val 6
Mix CC59 Feedback CC58
Modulation Speed
CC56
15
TREMOLO
CC55, val 2
Mix CC59 —
Modulation Speed
CC56
16
ROTARY
CC55, val 0
Mix CC59 Depth CC57
Modulation Speed
CC56
