Rode Classic II [10/16] Setting the polar pattern
![Rode Classic II [10/16] Setting the polar pattern](/views2/2008464/page10/bga.png)
Setting the Polar Pattern
- 10 -
Your Classic II can be adjusted to any of nine polar
patterns from omni, through cardioid to fi gure of
eight. This fl exibility allows recording of most
instruments and/or voices with absolute control.
• Select the preferred polar pattern. This is done
with the middle dial on the front of the Classic II
Power Supply. (The most commonly used pattern
for vocal recording is Cardioid – at the 12 o’clock
position).
• When the cardioid position is selected, the
microphone picks up sound from in front of the
microphone, and rejects sound from the rear.
• When in the omni position (fully anti-clockwise),
the microphone picks up sound from all around
the microphone and there is no proximity effect as
found in cardioid mode.
5
-5
-15
-25
-35
-45
-55
-60
-50
-40
-30
-20
-10
0
0
30
60
90
120
150
180
210
240
270
300
330
250 Hz
1 kHz
4 kHz
Front is picked up
Rear is rejected
