Rode Classic II [3/16] Specifi cations
![Rode Classic II [3/16] Specifi cations](/views2/2008464/page3/bg3.png)
- 3 -
Specifi cations
Acoustic
Principle:
Pressure gradient
Directional
Pattern:
Switchable Omnidirectional/
Cardioid / Figure-8 in nine steps
(see graph)
Frequency
Range:
20 Hz-20 kHz
(see graph)
Output
Impedence:
200Ω
Sensitivity: -37dB re 1V/Pa
(14mV @ 94dB SPL) +/-2dB
Equivalent Noise: <18 SPL
(A - weighted per IEC651)
Maximum
Output:
+2dBu
(@ 1kHz, 1% THD into 1KΩ)
Dynamic Range: >113 dB SPL
(A - weighted per IEC651)
Maximum SPL: 131dB SPL
(@ 1kHz, 1% THD into 1KΩ)
Signal/Noise: > 76dB SPL
(A - weighted per IEC651)
Power
Requirement:
Dedicated Power Supply
(110 ~ 120V/220 ~ 240V, 50/60 Hz)
Net Weight: 1440gm
Packed Weight: 9kg
