CONTROLS & CONNECTIONS

3.2 BACK PANEL LAYOUT

The back panel of the HP60 is divided into four sections: Power, the six numbered

Headphone Channels, Talkback and Inputs A & B.

3.2.1 Power

Power. The Power switch turns the HP60 on and off. The ‘ | ’ down is the ON position.

IEC Power Input.

The HP60’s power input connection accepts a standard IEC plug and is

rated for either 100-120 VAC or 220-230 VAC, depending upon the country it is

purchased in. Please check with your local retailer or dealer if you have any questions

concerning the input voltage of your HP60’s power supply.
