PRESONUS HP60 [8/20] Operation

OPERATION

2.1 QUICK START GUIDE

The goal of the HP60 Quick-Start guide is to help get your HP60 connected to your system as

quickly as possible. The following step-by-step instructions are based on a common studio

environment. Your actual setup may change based on your needs and applications.

Connect the Power

1) Turn every knob on the HP60’s front panel completely counterclockwise (left).

2) Connect the included IEC power cable to the HP60’s power input connector and to the

appropriate wall socket.

3) Flip the power switch to the ‘ON’ position (|= on).

Mix A, Mix B & Talkback Mic Connection and Level Adjustment

4) Connect your DAW (digital audio workstation) or Mixer Main Outputs to the Left and

Right TRS inputs of Input A on the back of your HP60.

5) Connect your DAW or Mixer auxiliary outputs (monitor mix / click track) to the Left

and Right TRS inputs of Input B on the back of your HP60.

6) Connect an XLR dynamic microphone to the

MIC

input on the back of your HP60.

7) Connect a pair of headphones to the Phones 1 output and turn its

Level

knob up to the

“12 o’clock position”.

8) Play a CD, session or other audio type typical to your studio through the source of

Input A (DAW or Mixer Outputs) and begin turning up the

Input A

knob until your

headphones are slightly above a comfortable / desired level.

9) Turn the Channel 1

Mix

knob fully clockwise (right). Repeat steps 7 & 8 for Input B

and the Talkback Microphone (You will need to press ‘Talk’ when setting mic level).
