ADJ Revo 4 LED [10/10] Auto sensing voltage
![ADJ Revo 4 LED [10/10] Auto sensing voltage](/views2/2008550/page10/bga.png)
Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Revo 4 Specifications
Model: Revo 4
Voltage: 100V~240V 60Hz/50Hz
LEDs: 256 LEDs (64 Red, 64 Green,
64 Blue, and 64 White)
Power Consumption: 29W
Beam Angle: 50 Degrees
Fuse: 7A
Power Cord Daisy Chain: 20 Fixtures Max.
Dimensions: 12.25”(L) x 12”(W) x 13.25”(H)
312mm x 306mm x 334mm
Weight: 10 Lbs. / 4.2 kgs.
Colors: RGB + White
Duty Cycle: None
DMX: 4 or 256 DMX Channels
Sound Active: Yes
Working Position: Any Safe, Secure Position
Warranty: 3 Year (1095 days)
©American DJ Supply
American DJ World Headquarters:
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.americandj.com / E-mail: info@americandj.com
American DJ Europe
Junostraat 2
6468 EW Kerkrade
Netherlands
service@americandjeurope.com / www.americandjeurope.com
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
Auto Sensing Voltage: This xture contains a electronic bal-
last, which will auto sense the voltage when it is plugged into the
power source.
American DJ® - www.americandj.com - Revo 4 Instruction Manual Page 19
