American DJ® - www.americandj.com - Revo 4 Instruction Manual Page 11
American DJ® - www.americandj.com - Revo 4 Instruction Manual Page 12
Universal DMX Control: This function allows you to use a Elation®
universal DMX-512 controller to control the chases and patterns,
dimmer and strobe. A DMX controller allows you to create unique
programs tailored to your individual needs.
1. The Revo 4 has 4 DMX channel mode and a 256 DMX channel
mode. To set the channel mode see page 8. See page 14 a for
detailed description of the DMX traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 5-7 as well as the set-up specifications that are
included with your DMX controller.
3. Use the controller’s faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instruction on page 8 to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Master-Slave Operation: This function will allow you to link up to
16 units together and operate without a controller. In Master-Slave
operation one unit will act as the controlling unit and the others will
react to the controlling units programs. Any unit can act as a Master
or as a Slave.
1. Using standard XLR microphone cables, daisy chain your units
together via the XLR connector on the rear of the units. Remem-
ber the Male XLR connector is the input and the Female XLR
connector is the output. The rst unit in the chain (master) will use
the female XLR connector only - The last unit in the chain will use
the male XLR connector only. For longer cable runs we suggest a
terminator at the last fixture.
2. On the Master unit find your desired show or choose sound act-
tive mode and set that by pressiing the ENTER button.
3. On the slave units tap the MENU button until “SLND” is display-
ed, and Press ENTER.
4. The slave units will now follow the Master unit.
5. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Revo 4 Operation
2. Press the UP button to select “DISP” to activate this function,
or “PISD” to deactivate this function.
3. Press ENTER to conrm.
TEST - This function will run a self test program.
1. Tap the MENU button until “TEST” is displayed, press ENTER.
2. The xture will now run a self test.
FHRS - With this function you can display the running time
of the unit.
1. Tap the either the MENU button until “FHRS” is displayed,
press ENTER.
2. The display shows the running time of the unit. Press MENU
to exit.
VER - Use this function to display the Software version of
the unit.
1. Tap the either the MENU button until “VER” is displayed,
press ENTER.
2. The display will show the software version.
