Руководство по эксплуатации Страница: 11

Alto ALTOGATE [11/15] Rack ounting m

TIP RING SLEEVE

SLEEVE TIP

SLEEVE RING TIP

TIP RING SLEEVE

Insert Leads

Centre (Send)

Screen

Centre (Return)

Screen

Tip

Ring

Sleeve

Tip (Send)

Sleeve

Tip

Ring

Sleeve

2 (Send)

2 (Return)

Tip

Ring

Sleeve

4.3 Rack ountingM

Please allow at least an additional 4" depth for the connectors on the rear panel. Be sure that there is enough air

space around the unit for sufficient ventilation and please do not place the LTO GATE on high temperature devices

such as power amplifiers etc. to avoid overheating.

The most secure mounting is on a universal rack shelf available from various rack manufactures or your music

dealer. The LTO GATE fits into one standard 19" rack unit of space.
