Alto ALTOGATE [12/15] Technical specifications
![Alto ALTOGATE [12/15] Technical specifications](/views2/2008642/page12/bgc.png)
11
AUDIO INPUT
AUDIO OUTPUT
FUNCTION
SWITCHES
GATE SECTION
IRC (Interactive Ratio Control) expander
5. TECHNICAL SPECIFICATIONS
Connectors
Type
Impedance
Connectors
Type
Max. Output Level
Impedance
Mode
Filter
Gain Reduction
"-" indicator
"Hold" indicator
"+" indicator
Type
Range
Threshold
Attack
Hold
Release
Type
Attack
Ratio
Frequency
Bandwidth
Frequency Response
Noise
THD
IMD
Crosstalk
AC 95-120 Vac 60Hz Fuse: T400mAL (slow below)
AC 210-240 Vac 50Hz Fuse: T200mAL (slow below)
3.3kg(7.27lb)
Max. Input Level
CMRR
XLR and 1/4" JACK
RF filtered, servo-balanced input
alanced: 50kOhm nbalanced: 25kOhmBU
Balanced and Unbalanced: +21dBu
XLR and 1/4" JACK
Electronically servo-balanced output stage
Balanced: 60 Ohm Unbalanced: 30 Ohm
Monitors the side-chain key signal
Activates FlexLink function
Expander/Gate switch
Activates the side-chain Filter
8-segment LED display: 1/3/6/10/15/20/30/40dB
Signal is above threshold
Signal reaches threshold
Signal is below threshold
UTR (Ultra Transient Response) gate
Variable: from 0 to -80dB
Variable: from BYPASS to +10dBu
Program dependent
Variable: from 0 to 4sec
Variable: from 0.05 to 4sec
Program dependent
Variable: from 1:1 to 1:4
Variable: from 100Hz to 10kHz
Variable: from 2.3 to 0.7 oct.
From 20Hz to 30kHz
>90dBu, unweighted, 22Hz to 22kHz
0.01% typ. @+4dBu, 1kHz, GAIN 1
0.01% typ. SMPTE
<-100dB, 22Hz to 22kHz
BUalanced and nbalanced: +21 dBu
typ.40dB, >55dB@1kHz
EXPANDER
SECTION
POWER SUPPLY
Monitor
Couple
INDICATORS
PARAMETRIC
SC FILTER
SYSTEM
SPECIFICATIONS
POWER
CONSUMPTION
18 Watts
DIMENSIONS
483(W) 194.5(D) 44(H)mm (19 7.7 1.7)
WEIGHT
