CLAVIA DMI AB CLAVIA NORD Stage 2 EX HP76 [94/101] Page 92

15. MIDI implementation: MIDI Controller list Nord Stage EX v6.x

Page 92

AmpSim Enable 87

Rotor Destination 88

Rotor Drive 89

Rotor Speed 90

Rotor Stop 91

Rotor Enable 92

Compressor Amount 93

Compressor Enable 94

Reverb Amount 95

Reverb Size 96

Reverb Enable 97

Organ Enable Sustain Pedal 98

Organ Octave Shift 99

Organ Level 100

Organ Enable 101

Organ KB Zone Assignment 102

Piano Enable PStick 103

Piano Enable Sustain Pedal 104

Piano Octave Shift 105

Piano Level 106

Piano Enable 107

Piano KB Zone Assignment 108

Synth Enable PStick 109

Synth Enable Sustain Pedal 110

Synth Octave Shift 111

Synth Level 112

Synth Enable 113

Synth KB Zone Assignment 114

Nord Stage Parameter MIDI Controller #
