Index Nord Stage EX v6.x
Page 96
G
Glide (Synth) 46
Global Effects
Compressor
54
Reverb 54
I
Instruments
Activating
13
Internal memory 71
Internet 6
K
KBT
Filter
45
Key click control (B-3 organ) 26
Keyboard
About
8
Keyboard splits 56
Keyboard Tracking
Filter
45
Keyboard Zones 56
Knobs
About
8
L
Legato mode 46
Live Buffer memory 19
Live Buffer mode 18
Live buttons 18
LP Filter (Synth) 44
M
Master level 7
Memory (internal) 71
Memory Protect 68
MIDI
about the implementation
74
channels
using with sequencer
75
connections 75
Controller list 78
controllers
"chasing" when using a sequencer
76
recording in sequencer 76
implementation chart 81
local on/off 75
Program Change 75
recording in sequencer 75
Program dump 76
send all MIDI controllers 77
Sysex dump of single Programs 76
Sysex reception of Program and Program
Banks
77
MIDI Page 68
Mod Envelope
Attack
41
Decay/Release 42, 43
Modulation Envelope 41
Repeat mode 42
Mono mode 46
Morph Assign
About
60
Assignable parameters 61
Clearing 62
Multiple keyboards 59
N
Note On/Off
MIDI transmission and reception
74
O
Octave Shift 58
Octave Shift (Extern section) 64
Organ B-3 section 24
Organ Key Click Level (Sound Page) 68
Organ Output 66
Organ Trig Mode 67
OS upgrades 73
Oscillator
Analog waveforms
36
Sync 38
Waveforms
Digital
41
FM 39
Pulse and Square wave 37
Sawtooth wave 36
Sine wave 38
Triangle wave 37
Oscillator section (Synth) 35
Output Level
Instrument
14
