LINE 6 StageSource L3m [16/24] L6 lin

about L6 Link

tm

L6LINKisaproprietarydigitalnetworkingprotocoldevelopedbyLine6toenableeasy,reliable,one-cableconnectivitybetweenvariousLine6products.

UptonineL3t/L3mandnineL3sspeakerscanbeconnectedviaL6LINK,andchannelassignmentisautomatic,withtherstspeakerinthechain

(master)providingthedigitalaudiochannelsdistributedtoallotherspeakersinthenetwork.AllL3sandvertically-orientedL3t/L3mspeakersfollow

channelassignmentshowninthetablebelow.Forexample,connectingtwouprightL3torL3mspeakerstogetherautomaticallyconguresthemasleft

andright.ConnectingthreeuprightL3t/L3mspeakerstogetherconguresthemasleft,monocenter(left+right),andright.PlacinganyL3t/L3minthe

L6LINKnetworkonitssideassumesitwillbeusedasaoormonitor,conguresitasleft+right,andtheremainingspeakersfollowthebehaviorinthe

tablebelow.Eachspeaker’srearpanelL6LINKdisplaywillindicatethecurrentassignment:Left(“L”),right(“r”),orL+R(“b”forboth).

standardXLRcablesmayyieldinconsistentresultsbecauseofthevaryingqualityofcommercially-availableXLRcables.Cableslongerthan50feetare

notrecommendedforL6LINK.

Number of L3s or Vertical

L3t/L3m speakers

Default Audio Channel Assignment

Spkr 1 Spkr 2 Spkr 3 Spkr 4 Spkr 5 Spkr 6 Spkr 7 Spkr 8 Spkr 9

1 L+R

2 L R

3 L L+R R

4 L L R R

5 L L L+R R R
