Setup Details
2•2
Expression Pedals
In LCD 1 you set up your expression pedal assignments. You’ll also see your current
firmware version number displayed in the upper left corner. Any or all 4 FX Units in the
M13 can be controlled by an expression pedal. You can use up to 2 pedals at once. Each
can be assigned to an FX Unit or the Looper. You have 3 selection choices here: Pedal
1, Pedal 2, or Off. Knobs 1 & 2 set the assignments for FX 1 & FX 2, Knob 3 sets the
assignment for the Looper, and Knobs 4 & 5 set the assignments for FX 3 & FX 4.
*Looper pedal control is a global setting. FX pedal control settings are saved per Scene.
See Chapter 3 for more details on how to set up heel and toe expression pedal settings.
Expression Pedals
FX3:PDL1 FX4:PDL1
FX2:PDL1
FX1:PDL1
LPR:PDL2
V. 2.0
LPR:PDL1
LPR:OFF
FX1:OFF
FX1:PDL2
FX3:OFF
FX3:PDL2
FX2:OFF
FX2:PDL2
FX4:0FF
FX4:PDL2
Tempo LprLvl LprEQ
OVERDUB LO CUT
HI CUT
PLAY
HI CUT
LO CUT
PLAY
OVERDUB
100.0BPM
Tempo, Looper Levels & EQ
We’ve added a new Tempo control displayed in the lower left of LCD 2, adjustable by
turning Knob 3. There are also two Looper Levels to set up in LCD 2. The first is Play,
which determines the volume of your Looper’s playback as balanced with your live guitar.
The second is Overdub, which determines the volume of your loop in Overdub mode. To
clarify, if your Overdub Level is set to 90%, each time your loop begins a new overdub its
volume will be reduced by 10%, sounding quieter and quieter with each overdub pass. The
default level for both Play and Overdub is 100%. Use Knobs 1 and 4 to adjust these levels.
With Knobs 2 and 5 you can adjust Looper Hi Cut and Lo Cut EQ levels. Hi Cut rolls off
the high end for loop playback (@2kHz), and Lo Cut rolls off the low end (@500Hz). If
applied, this EQ affects the sound of loop playback only, having no effect on live guitar.
