Appendix A : Reference

A•1

Expression Pedal 1 1 0 to 127

Expression Pedal 2 2 0 to 127

Tap Tempo 64 2 taps determine tempo

Appendix A : reFerence

MIDI Control

The M13 will send and receive MIDI CC and Program Change messages on any MIDI

Channel from 1 thru 16 or Omni, selectable from the M13 Setup mode, LCD 4. MIDI

implementation includes MIDI CCs for Looper Control, FX Unit On and Bypass messages,

Tap Tempo, Expression Pedal CCs and Program Change messages for Scene select. It is

therefor possible to control the M13 from a MIDI controller or a computer sequencer.

The most common application would probably be to use a separate MIDI controller to

control the M13 Looper, so that all 12 Scene select switches on the M13 would be available

for individual FX control.

Individual Model selection and assignment for each FX Unit from the 5 different FX groups

is not implemented, but individual FX loaded into the A, B and C memory locations of all

4 FX Units can be engaged or bypassed via MIDI CCs. The MIDI Reference Tables in this

chapter represent the currently implemented MIDI spec.

Looper & Expression Pedals

M13 Footswitch MIDI CC# Looper Function

Record/Overdub 50 0 to 63 = Overdub 64 to 127 = Record

Play/Stop 28 0 to 63 = Stop 64 to 127 = Play

Half Speed 36 Toggles between Half Speed & Normal Speed

Reverse 85 Toggles Reverse On or Off

Undo/Redo 82 Activates Undo/Redo

Play Once 80 Activates Play Once function

Pre/Post 84 0 to 63 = Pre 64 to 127 = Post

Looper Control 86 0 to 63 = Exit 64 to 127 = Enter
