Appendix A : Reference
A•3
BPM / Milliseconds
BPM 1/4 Note 1/8 Note 1/16 Note 1/4 Triplet 1/8 Triplet 1/32 Note
80 750 375 187.5 500 250 94
82 732 366 183 488 244 91
84 714 357 178 476 238 89
86 698 348 174 465 233 87
88 682 341 170 455 227 85
90 667 333 167 444 222 83
92 652 326 163 435 217 82
94 638 319 159 426 213 80
96 625 312 156 417 208 78
98 612 306 153 408 204 77
100 600 300 150 400 200 75
102 588 294 147 392 196 74
104 577 288 144 385 192 72
106 566 283 142 377 189 71
108 555 277 139 370 185 69
110 545 272 136 364 182 68
112 536 268 134 357 179 67
114 526 263 132 351 175 66
116 517 259 129 345 172 65
118 508 254 127 339 169 64
120 500 250 125 333 167 63
122 492 246 123 328 164 61
124 484 242 121 323 161 60
126 476 238 119 317 159 60
128 469 234 117 312 156 59
130 462 231 115 308 154 58
132 455 227 113 303 152 57
