4 ULTRA-DI DI100 User Manual
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. Apolarized
plug has two blades with one wider than the
other. A grounding-type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
Ifthe provided plug does not t into your
outlet, consult an electrician for replacement
of the obsoleteoutlet.
10. Protect the power cord from being
walked on or pinched particularly at plugs,
convenience receptacles, and the point where
they exit from theapparatus.
11. Use only attachments/accessories
specied by themanufacturer.
12. Use only with
the cart, stand, tripod,
bracket, ortable
specied by the
manufacturer, orsold
with the apparatus.
When a cart is used, usecaution when moving
the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning
storms or when unused for long periods
oftime.
14. Refer all servicing to qualied service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, orhas beendropped.
15. The apparatus shall be connected to
a MAINS socket outlet with a protective
earthingconnection.
16. Where the MAINS plug or
an appliance coupler is used as
the disconnect device,
thedisconnect device shall
remain readilyoperable.
TECHNICAL SPECIFICATIONS AND
APPEARANCES ARE SUBJECT TO CHANGE
WITHOUT NOTICE AND ACCURACY IS NOT
GUARANTEED. BEHRINGER, KLARKTEKNIK,
MIDAS, BUGERA, ANDTURBOSOUND
ARE PART OF THE MUSIC GROUP MUSIC
GROUP.COM. ALL TRADEMARKS ARE THE
PROPERTY OF THEIR RESPECTIVE OWNERS.
MUSICGROUP ACCEPTS NO LIABILITY FOR
ANY LOSS WHICH MAY BE SUFFERED BY
ANY PERSON WHO RELIES EITHER WHOLLY
OR IN PART UPON ANY DESCRIPTION,
PHOTOGRAPH OR STATEMENT CONTAINED
HEREIN. COLORSAND SPECIFICATIONS
MAY VARY FROM ACTUAL PRODUCT. MUSIC
GROUP PRODUCTS ARE SOLD THROUGH
AUTHORIZED FULLFILLERS AND RESELLERS
ONLY. FULLFILLERS AND RESELLERS ARE
NOT AGENTS OF MUSICGROUP AND HAVE
ABSOLUTELY NO AUTHORITY TO BIND
MUSICGROUP BY ANY EXPRESS OR IMPLIED
UNDERTAKING OR REPRESENTATION. THIS
MANUAL IS COPYRIGHTED. NO PART OF
THIS MANUAL MAY BE REPRODUCED OR
LEGAL DISCLAIMER
