5 ULTRA-DI DI100 User Manual
TRANSMITTED IN ANY FORM OR BY ANY
MEANS, ELECTRONIC OR MECHANICAL,
INCLUDING PHOTOCOPYING AND RECORDING
OF ANY KIND, FORANY PURPOSE, WITHOUT
THE EXPRESS WRITTEN PERMISSION OF
MUSICGROUPIPLTD.
ALL RIGHTS RESERVED.
© 2013 MUSICGROUPIPLTD.
TRIDENT CHAMBERS, WICKHAMS CAY,
P.O. BOX 146, ROAD TOWN, TORTOLA,
BRITISHVIRGIN ISLANDS
For the applicable warranty terms and
conditions and additional information
regarding MUSIC Group’s Limited Warranty,
please see complete details online at
www.music-group.com/warranty.
LIMITED WARRANTY
Содержание
- Professional battery phantom powered di box 1
- Ultra di di100 1
- User manual 1
- Table of contents 2
- Thank you 2
- Welcome to behringer 6
- Control elements 7
- Di100 configurations 8
- Tapping signal from the bass guitar 8
- Converting the output of a keyboard dj mixer headphone plug 9
- This configuration can be used with a keyboard dj mixer headphone output drum kit or any stereo or mono line source in all cases where you want to run long lines for instance to the foh front of house desk in most cases the best setting is achieved by depressing one of the 20 db pad buttons to avoid overloading the foh desk input the signal can be linked through to another amplifier if the keyboard player dj etc wants to have a monitor connected independent of the foldback mix the ultra di acts as both a ground isolator and an unbalanced to balanced converter 9
- This figure shows the standard application of any direct injection box the signal to the amplifier is unaffected it is just tapped off to be routed to the microphone input of the mixer especially bass guitars benefit from this application it is difficult to find a microphone which handles high level low frequencies well and with a linear frequency response using the ultra di will give you clean and crisp sound connect the ultra di after any effects devices so that their effect will be heard over the p a system or on the recording if the mixer provides phantom power between 20 v and 52 v the internal battery of the di100 will automatically be detached you should chose this possibility whenever possible to save battery power 9
- Converting a microphone from high impedance unbalanced to low impedance balanced 10
- Tapping a signal from a power amplifier output 10
- Specifications 11
