User's Guide HDSPe AIO © RME

29. Technical Specifications

29.1 Analog

AD – Line In

• Resolution AD: 24 Bit

• Signal to Noise ratio (SNR): 113 dB RMS unweighted, 116 dBA @ 44.1 kHz

• THD @ -3 dBFS: -101 dB, < 0.001 %

• THD+N @ -3 dBFS: -99 dB, < 0.0015 %

• Crosstalk: 108 dB

• Frequency response AD @ 44.1 kHz, -0.5 dB: 5 Hz - 21.5 kHz

• Frequency response AD @ 96 kHz, -0.5 dB: 5 Hz – 45.3 kHz

• Frequency response AD @ 192 kHz, -1 dB: 5 Hz - 74 kHz

• Input Line: phono unbalanced, optional XLR balanced

• Input impedance: 10 kOhm

• Input sensitivity: Lo Gain, +4 dBu, -10 dBV

• Input level for 0 dBFS @ Lo Gain: +19 dBu

• Input level for 0 dBFS @ +4 dBu: +13 dBu

• Input level for 0 dBFS @ -10 dBV: +2 dBV

DA – Line Out

• Resolution DA: 24 Bit

• Signal to Noise ratio (SNR): 116 dB RMS unweighted, 119 dBA @ 44.1 kHz (unmuted)

• THD: < - 104 dB, < 0.00063 %

• THD+N: < -100 dB, < 0.001 %

• Crosstalk: > 110 dB

• Maximum output level: +19 dBu

• Frequency response @ 44.1 kHz, -0.5 dB: 5 Hz – 22 kHz

• Frequency response @ 96 kHz, -0.5 dB: 5 Hz – 34 kHz

• Frequency response @ 192 kHz, -1 dB: 5 Hz – 50 kHz

• Output Line: phono unbalanced, optional XLR balanced

• Output impedance: 50 Ohm

• Output level: Hi Gain, +4 dBu, -10 dBV

• Output level at 0 dBFS @ Hi Gain: +19 dBu

• Output level at 0 dBFS @ +4 dBu: +13 dBu

• Output level at 0 dBFS @ -10 dBV: +2 dBV

DA - Phones Output

As Line out, but

• Output: Standard 6.3 mm / 1/4" TRS jack

• Output impedance: 30 Ohm
