76
User's Guide HDSPe AIO © RME
Therefore, in a digital loopback test a negative offset of about 2 ms occurs. This is no real
problem, because this way of working is more than seldom, and usually the offset can be com-
pensated manually within the application. Additionally, keep in mind that even when using the
digital I/Os usually at some place an AD- and DA-conversion is involved (no sound without DA-
conversion...).
Note
: Cubase and Nuendo display the latency values signalled from the driver separately for
record and playback. While with our digital cards these values equal exactly the buffer size (for
example 3 ms at 128 samples), the HDSPe AIO displays the time needed for the AD/DA-
conversion.
Core Audios Safety Offset
Under OS X, every audio interface has to use a so called satety offset, otherwise Core Audio
won't operate click-free. The HDSPe AIO uses a safety offset of 32 samples. This offset is sig-
nalled to the system, and the software can calculate and display the total latency of buffer size
plus AD/DA offset plus safety offset for the current sample rate.
30.3 DS - Double Speed
When activating the Double Speed mode the HDSPe AIO operates at double sample rate. The
internal clock 44.1 kHz turns to 88.2 kHz, 48 kHz to 96 kHz. The internal resolution is still 24 bit.
Sample rates above 48 kHz were not always taken for granted, and are still not widely used
because of the CD format (44.1 kHz) dominating everything. Before 1998 there were no re-
ceiver/transmitter circuits available that could receive or transmit more than 48 kHz. Therefore a
work-around was used: instead of two channels, one AES line only carries one channel, whose
odd and even samples are being distributed to the former left and right channels. By this, you
get the double amount of data, i. e. also double sample rate. Of course in order to transmit a
stereo signal two AES/EBU ports are necessary then.
This transmission mode is called Double Wire in the professional studio world, and is also
known as S/MUX (abbreviation for Sample Multiplexing) in connection with the ADAT format.
The AES3 specification uses the uncommon term Single channel double sampling frequency
mode.
Not before February 1998, Crystal shipped the first 'single wire' receiver/transmitters that could
also work with double sample rate. It was then possible to transmit two channels of 96 kHz data
via one AES/EBU port.
But Double Wire is still far from being dead. On one hand, there are still many devices which
can't handle more than 48 kHz, e. g. digital tape recorders. But also other common interfaces
like ADAT or TDIF are still using this technique.
Because the ADAT interface does not allow for sampling frequencies above 48 kHz (a limitation
of the interface hardware), the HDSPe AIO automatically uses the Sample Multiplexing method
in DS mode. One channel's data is distributed to two channels according to the following table:
ADAT Ch. 1 2 3 4 5 6 7 8
DS Channel
Samples
1
1a
1
1b
2
2a
2
2b
3
3a
3
3b
4
4a
4
4b
As the transmission of double rate signals is done at standard sample rate (Single Speed), the
ADAT outputs still deliver 44.1 kHz or 48 kHz.
The SPDIF (AES) output of the HDSPe AIO provides 96 kHz as Single Wire only.
