7. Technical Specifications

Microphone type: Stereo condenser microphone

Diaphragm: Large condenser – double-sided 6u gold-sputtered membranes

Diaphragm diameter: 34mm

Polar pattern: Multi-pattern (cardioid, figure-8, omnidirectional)

Frequency response: 20HZ ~ 20kHZ

Sensitivity: -35dB | 18mV/Pa (-1 to +3dB)

THD+N: -116dB

Self-noise: 19dB(A)

SNR: 75dB(A)

Output impedance: 50 Ohms @ 1kHz

Power requirements: 48V DC phantom power

Output connector: 5-pin male XLR

Color: Black matte

Weight (mic body): 1.23 lbs (560 grams)

Dimensions (mic body): 8.6" x 2.1" (219mm x 53mm)

Package contents:

Breakout cable: 16.4' (5 meters) 5-pin female XLR to dual 3-pin male XLR (high grade OFC Y-cable)

Mount: Shock absorber type

Case: Standard mid-size road case with handle and custom-fit foam inserts

Can be transformed into a vintage replica via the Antelope Audio Mic Emulation Packs.

Vintage Mic Emulations:

Berlin 47 FT


