Antelope Audio Edge Duo [3/13] Safety notes

Edge Duo is a modelling microphone by Antelope Audio, suited for the manufacturer’s real-time mic preamp modelling.

Combined with the already highly acclaimed Antelope Audio FPGA Vintage Compressors & EQs, this new modelling

microphone will comprise a true cutting-edge front end that will usher in a new era for modern recording.

Edge microphones feature dual edge-terminated capsules for a smooth/natural sound, reproducing the expressiveness

and character of expensive classic microphones. Antelope founder Igor Levin designed the ground-breaking, fully

discrete electronics. The hand-selected capsules are encased in a carefully crafted enclosure with contours and shape

3. Connecting Edge Duo

Edge Duo comes with an Y-XLR cable. Each of the 3-pin XLR cable ends convey the signal from the Front & Back

membranes of the microphone.

In order to use the microphone with the Antelope Audio Mic Emulations, you need to connect both cables to

neighbouring mic preamps on your Antelope Audio Interface.

Phantom power is required on both channels (Red & White cables).

Edge Duo can be used in mono as a standard cardioid mic. However, using it as such, you won’t be able to use the

Antelope Audio FPGA Mic Modelling system.

4. Claim and assign features

Assigning features:

Open the interfaces Control Panel and go to the Help tab (the “?” button)

Open the Administration panel

Mark “Register device and assign features” and continue

Mark the checkbox with the Microphone Emulations and continue

The device will restart and your new Mic Emulations will be available.

5. Load a Mic Emulation in your Antelope Audio Interface.

Open the interface Control Panel and click on the little settings icon on the preamp gain control.

To have access to the mic settings, the input should be in Mic mode.
