ADJ Products, LLC - www.adj.com - Stinger Gobo Instruction Manual Page 3
ADJ Products, LLC - www.adj.com - Stinger Gobo Instruction Manual Page 2
Stinger Gobo General Information
Unpacking: Thank you for purchasing the Stinger Gobo by ADJ
Products, LLC. Every Stinger Gobo has been thoroughly tested and
has been shipped in perfect operating condition. Carefully check the
shipping carton for damage that may have occurred during shipping.
If the carton appears to be damaged, carefully inspect your xture for
any damage and be sure all equipment necessary to operate the unit
has arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for fur-
ther instructions. Please do not return this unit to your dealer without
contacting customer support rst.
Introduction: The Stinger Gobo is a DMX intelligent LED moonflower,
strobe, & laser fixture. The Stinger Gobo has 2 DMX channel modes, a
2 channel mode and 14 channel mode. The fixture can operate in as a
stand alone fixture or in a Master/Slave set up. The Stinger Gobo has
three operating modes; sound active, show mode, and DMX Control.
For best results use fog or special effects smoke to enhance the beams
projections.
Customer Support: ADJ Products, LLC provides a toll free cus-
tomer support line, to provide help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.adj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@adj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! This may cause eye damage. Avoid looking directly into the
light source. Use sensible precaution.
Stinger Gobo Features
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact ADJ Products, LLC.
During operation the housing may become extremely hot. Avoid touch-
ing the unit with bare hands while in use.
ADJ Products, LLC will not accept any liability for any resulting dam-
ages caused by the non-observance of this manual or any unauthor-
ized modication to this unit.
Stinger Gobo Handling Precautions
Stinger Gobo Warranty Registration
The Stinger Gobo carries a 1 Year limited warranty. Please fill out
the enclosed warranty card to validate your purchase and warranty.
You may also register your product online at www. americandj.com.
All returned service items whether under warranty or not, must be
freight pre-paid and accompany a return authorization (R.A.) number.
If the unit is under warranty you must provide a copy of your proof of
purchase invoice. Please contact ADJ customer support for a R.A.
number.
To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.
Stinger Gobo General Instructions
• 2 DMX Channel Mode’s: 2 Channel and 14 Channel)
• 3 Operating Modes - Sound Active, Show Mode, & DMX Control
• RGBWA LED’s
• Green & Red Lasers
• Internal Microphone
• Digital Display for Address and Function Setting
• Power Cord Daisy Chain
• UC IR Compatible (Not Included) & Airstream IR Compatible
(transmitter not included)
