ADJ Products, LLC - www.adj.com - Stinger Gobo Instruction Manual Page 16 ADJ Products, LLC - www.adj.com - Stinger Gobo Instruction Manual Page 17
Universal DMX Control: This function allows you to use a univer-
sal DMX-512 controller to control the patterns, rotation and strobing.
A DMX controller allows you to create unique programs tailored to
your individual needs.
1. The Stinger Gobo is a 2 DMX channel modes; a 2 channel mode
and 14 channel mod. See pages 20-22 for detailed description of
the DMX values and traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 7-9 as well as the set-up specifications that are
included with your DMX controller.
3. Follow the instructions on page 13 to select your desired DMX
channel mode and set the DMX address.
4. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
5. For help operating in DMX mode consult the manual included
with your DMX controller.
Sound Active Mode: This mode allows a single unit or several units
linked together, to run to the beat of the music.
1. Press the MENU button until “Soun” is displayed, and press
ENTER.
2. Press the UP or DOWN buttons to either activate sound active
mode or deactivate, and press ENTER. The unit will now run to
the beat of the music.
3. The sound sensitivity can be adjusted by pressing the MENU
button until “Sose” is displayed, and then press ENTER. Use the
UP or DOWN buttons to adjust the sound sensitivity, 0 being the
least sensitive, and 100 being the most sensitive.
Show Mode: This mode allows a single unit or several units linked
together, to run 1 of 6 built-in shows.
1. Press the MENU button until “Shnd” is displayed, and press
ENTER.
2. Press the UP or DOWN buttons to nd your desired show and
press ENTER. The unit will now run your chosen built-in program.
3. The show running speed can be adjusted by pressing the MENU
button until “SPEE” is displayed, and then press ENTER. Use the
UP or DOWN buttons to adjust the sound sensitivity, 0 being the
slowest, and 100 being the fastest running speed.
Stinger Gobo Operation Stinger Gobo System Menu
2. Use the UP or DOWN buttons to either activate strobing or deacti-
vate it.
TEST - This function will run a self test program.
1. Press the MENU button until “TEST” is displayed, press ENTER.
2. The xture will now run a self test.
DISP - This function will reverse the display 180º.
1. Press the MENU button until “DISP” is displayed, press ENTER.
2. Press ENTER to “ip” the display. Press ENTER to “ip” it again.
Press ENTER when you have made your desired setup.
3. Press ENTER to conrm. To make you LED display reappear again
press any button.
FHRS - With this function you can display the running
time of the unit.
1. Press the MENU button until “FHRS” is displayed, press ENTER.
2. The running time of the xture will now be displayed. Press MENU
to exit.
VER - Use this function to display the Software version of
the unit.
1. Press the either the MENU button until “VER” is displayed, press
ENTER.
2. The display will show the software version.
RSET - This function will reset the unit.
1. Press the MENU button until “RSET” is displayed. Press the
ENTER button and the unit will reset itself.
