ADJ Products, LLC - www.adj.com - Stinger Gobo Instruction Manual Page 14 ADJ Products, LLC - www.adj.com - Stinger Gobo Instruction Manual Page 15
Stinger Gobo System Menu
NODN - This mode can be used as a precaution mode,
that in case the DMX signal is lost, interrupted, or power is
lost, the operating mode chosen in the setup is the running
mode the xture will go into when the DMX signal is lost. You
can also set this as the operating mode you would like the
unit to return to when power is applied.
1. Press the MENU button until “NODN” is displayed, and either
“MASL”, “BLND”, or “LAST” will be displayed beneath.
2. Press ENTER and the bottom choice will begin to ash. Use the UP
or DOWN buttons to choose an operating mode you would like the unit
to start up in when power is applied or the DMX signal is lost.
• HOLD - If the DMX signal is lost the xture will stay in the last DMX
setting. If power is applied and this mode is set, the unit will automati-
cally go into the last DMX set up.
• PRGN (Master Slave) - If the DMX signal is lost or power is applied,
the unit will automatically go into Master Slave mode and run a built-in
show.
• BLAC (Blackout) - If the DMX signal is lost or interrupted, the unit will
automatically go into stand by mode.
3. Press ENTER to conrm your desired set up.
LED - With this function you can have the LED display
turn off after 10 seconds.
1. Press the MENU button until “LED” is displayed, press ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to keep the LED display on at all
times, or “OFF” to switch to have the LED display switch o after 10
seconds.
STRO - This will activate strobing.
1. Press the MENU button until “STRO” is displayed, press ENTER.
Stinger Gobo System Menu
2. A number between 0-100 will now be displayed, the number is the
current speed setting. Use the UP or DOWN buttons to adjust the
show speed. “0” being the slowest speed and “100” being the fastest.
3. Press ENTER to set the speed then press and hold the MENU
button for at least 3 seconds to show mode.
SLND - This will let you set unit as a master or slave in a
master/slave conguration.
1. Press the MENU button until “SLND” is displayed, press ENTER.
Either “MAST”, “SL 1”, or “SL 2” will be displayed.
2. Press the UP or DOWN buttons until your desired setting is dis-
played, press ENTER to conm.
NoTE: In a Master/Slave conguration you can set one xture to
Master and then set the next xture to “SL 2”, the xtures will now
have contrast movement to each other.
SOUN - Sound Active mode.
1. Press the MENU button until “SOUN” is displayed, press ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to activate sound active mode, or
“OFF” to deactivate sound active mode.
3. Press ENTER to conrm.
SOSE - In this mode you can adjust the sound sensitiv-
ity.
1. Press the MENU button until “SOSE” is displayed, press ENTER.
2. A number between 0-100 will be displayed. Press the UP or DOWN
buttons to adjust the sound sensitivity. 0 being the least sensitive,
and 100 being the most sensitive.
3. When you have found your desired setting press ENTER to conrm.
