ENGINE
Model VQ35DE VK45DE
Type Gasoline, 4-cycle Gasoline, 4-cycle
Cylinder arrangement
6-cylinder, V-slanted
at 60°
8-cylinder, V-slanted
at 90°
Bore 3 Stroke in (mm)
3.760 3 3.205 (95.5
3 81.4)
3.661 3 3.256 (93.0
3 82.7)
Displacement cu in (cm
3
) 213.45 (3,498) 274.2 (4,494)
Firing order 1-2-3-4-5-6 1-8-7-3-6-5-4-2
Idle speed rpm
See the emission control information label
on the underside of the hood.
Ignition timing (B.T.D.C.) degree/rpm
Spark plug
Standard PLFR5A-11 PLFR5A-11
Service option
Hot type PLFR4A-11 PLFR4A-11
Cold type PLFR6A-11 PLFR6A-11
Spark plug gap (Normal) in (mm) 0.043 (1.1) 0.043 (1.1)
Camshaft operation Timing chain Timing chain
The spark ignition system of this vehicle meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
TI0001-E
VQ35DE
SPECIFICATIONS
Technical and consumer information 9-7
w 07.3.7/S50-D/V5.0 X
