if the front passenger’s seat belt is not
fastened when the front passenger’s seat
is occupied. For 5 seconds after the igni-
tion switch is in the ON position, the sys-
tem does not activate the warning light
for the front passenger.
See “Seat belts” in the “1. Safety —
Seats, seat belts and supplemental re-
straint system” section for precautions on
seat belt usage.
Supplemental air bag
warning light
After turning the ignition switch to the ON
position, the supplemental air bag
warning light will illuminate. The supple-
mental air bag warning light will turn off
after about 7 seconds if the system is op-
erational.
If any of the following conditions occur,
the front air bag, side air bag, curtain and
rollover air bag and pretensioner system
need servicing and your vehicle must be
taken to an INFINITI dealer:
O The supplemental air bag warning
light remains on after approximately 7
seconds.
O The supplemental air bag warning
light flashes intermittently.
O The supplemental air bag warning
light does not come on at all.
Unless checked and repaired, the supple-
mental restraint system (air bag system)
and/or pretensioners may not function
properly. For additional information, see
“Supplemental restraint system” in the
“1. Safety — Seats, seat belts and supple-
mental restraint system” section.
WARNING
If the supplemental air bag warning light is
on, it could mean that the front air bag, side
air bag, curtain and rollover air bag systems,
and/or pretensioner systems will not op-
erate in an accident. To help avoid injury to
yourself or others, have your vehicle
checked by an INFINITI dealer as soon as
possible.
INDICATOR LIGHTS
Automatic transmission
position indicator light
When the ignition switch is turned to the
ON position, the indicator in the tachom-
eter shows the automatic transmission
selector lever position. See “Driving with
automatic transmission” in the “5.
Starting and driving” section.
Cruise main switch
indicator light (Green)
The light comes on when the cruise con-
trol is pushed. The light goes out when
the main switch is pushed again. While
the cruise control system main switch in-
dicator light is on, the cruise control sys-
tem is operational.
Cruise set switch indicator
light
The light comes on while the vehicle
speed is controlled by the cruise control
system. If the light blinks while the en-
gine is running, it may indicate the cruise
control system is not functioning prop-
erly. Have the system checked by an
INFINITI dealer.
Instruments and controls 2-15
w 07.8.9/S50-D/V5.0 X
