O INFINITI recommends that child re-
straints be installed in the rear seat.
However, if you must install a forward
facing child restraint in the front passen-
ger seat, move the passenger seat to the
rearmost position. Also, be sure the front
passenger air bag status light is illumi-
nated to indicate the passenger air bag
is OFF. See “Front passenger air bag and
status light” in this section for details.
O The three-point seat belt in your vehicle
is equipped with an Automatic Locking
Retractor (ALR) which must be used
when installing a child restraint.
O Failure to use the ALR mode will result in
the child restraint not being properly se-
cured. The restraint could tip over or oth-
erwise be unsecured and cause injury to
the child in a sudden stop or collision.
Also, it can change the operation of the
front passenger air bag. See “Front pas-
senger air bag and status light” in this
section.
O When using the rear center seat belt to
install a child restraint, make sure the
connector tongue and the seat belt
tongue are secured. Do not use the seat
belt with only the seat belt tongue at-
tached. This could result in serious per-
sonal injury in case of an accident or
sudden stop.
O A child restraint with a top tether strap
should not be used in the front pas-
senger seat.
The instructions in this section apply to
child restraint installation using the ve-
hicle seat belts in the rear seat or the
front passenger seat.
Front-facing
Follow these steps to install a front-facing
child restraint using the vehicle seat belt
in the rear seat or in the front passenger
seat:
1. Adjust the seatback so that it is up-
right.
O Do not move the seats with the child
restraints attached to them.
2. If you must install a child restraint in
the front seat, it should be placed in a
front-facing direction only. Move the
seat to the rearmost position. Child re-
SSS0640
Front facing (front passenger seat) — step 2
1-28 Safety — Seats, seat belts and supplemental restraint system
w 07.11.26/S50-D/V5.0 X
