Preview Function warning
light (Orange: if so
equipped)
The light comes on if there is a malfunc-
tion in the Brake Assist (with Preview
Function) system.
Run-flat tire warning light (if
so equipped)
Your vehicle is equipped with a Tire Pres-
sure Monitoring System (TPMS) that moni-
tors the tire pressure of all tires except
the spare.
The run-flat tire warning light warns of a
flat tire.
After the ignition switch is turned ON, this
light illuminates for about 1 second and
turns off.
If the vehicle is being driven with one or
more flat tires, the warning light will illu-
minate continuously and a chime will
sound for 10 seconds.
The chime will only sound at the first indi-
cation of a flat tire and the warning light
will illuminate continuously. When the
Flat tire warning is activated, have the
system reset and the tire checked and re-
placed if necessary by an INFINITI dealer.
Even if the tire is inflated to the specified
COLD tire pressure, the warning light will
continue to illuminate until the system is
reset by an INFINITI dealer.
If you select the tire pressure information
in the display, the LOW PRESSURE
warning message will be displayed. The
tire pressure for each tire will also be dis-
played.
Your vehicle can be driven for a limited
time on a flat tire. See “Run-flat tires” in
the “8. Maintenance and do-it-yourself”
section.
For additional information, see “Tire Pres-
sure Monitoring System (TPMS)” in the “5.
Starting and driving” section and in the
“6. In case of emergency” section.
WARNING
O If the light does not illuminate with the
ignition switch turned ON, have the ve-
hicle checked by an INFINITI dealer as
soon as possible.
O Although you can continue driving with
a punctured run-flat tire (if so equipped),
remember that vehicle handling stability
is reduced, which could lead to an acci-
dent and personal injury. Also, driving a
long distance at high speeds may
damage the tires.
O Do not drive at speeds above 55 MPH (88
km/h) and do not drive more than 50
miles (80 km) with a punctured run-flat
tire (if so equipped). The actual distance
the vehicle can be driven on a flat tire de-
pends on outside temperature, vehicle
load, road conditions and other factors.
O Do not tow a trailer when a run-flat tire
(if so equipped) is flat.
Seat belt warning light and
chime
The light and chime remind you to fasten
seat belts. The light illuminates whenever
the ignition switch is turned to ON, and
will remain illuminated until the driver’s
seat belt is fastened. At the same time,
the chime will sound for about 6 seconds
unless the driver’s seat belt is securely
fastened.
The seat belt warning light will illuminate
2-14 Instruments and controls
