Instruction manualMA30 - MA60

that the vox circuit of MIC is active. The vox circuit will not be

active when MIC is not lit

(front button 2).

6. MIC volume control: this knob determines the output volume of

MIC.

7. Name ﬁeld: here you can attach the source name stickers supplied

with the unit.

8. Input 2 selection button: by pressing this button, you can select

input 2, or switch off the selected input by pressing the button

when it is lit. You can only select one input at a time.

Note: you can switch on MIC and input 1 or 2 simultaneously. The

volume of MIC is determined by knob (6). Volume knob (4) has

no inﬂuence on the output volume of MIC. When the vox circuit

from MIC is enabled, MIC will attenuate the input 1-2 signal

(30dB attenuation). The emergency input and paging microphone

levels and settings can only be set at the rear panel, out of reach

of the enduser.

Standby

The auto standby function can be enabled/disabled via a switch (7)

at the rear of the unit. The power/standby knob led will slowly fade

in/out to indicate that standby is activated.

Basically, there are 2 standby modes:

• manual standby: activated by pushing the power button on the

front.

• auto standby: activated by the auto standby circuitry.
