Using the PCM96 sUrroUnd

Powering UP the PCM96 sUrroUnd

1. Plug in the power cord.

2. Press the Power button.

3. The Lexicon

logo appears, and remains until the boot process is com-

plete. Next, the Preset screen appears, showing the currently loaded pre-

set.

the Preset sCreen

The Preset screen is the starting point for many of the instructions in this

manual, so it’s a good idea to know how to get to the Preset screen. In most

cases, pressing the Back button one or more times will take you back to the

Preset screen. If you press the Back button while viewing the Preset screen,

you’ll arrive at the Machine or System Category Selection screen. In this

case, just turn the Select knob to select a category (the current category is

marked with an asterisk), and press the Select knob to load it. You will then

be taken to the Preset screen.

The Preset screen shows the current preset and configuration. Note that the

Preset screen has two “views”: System view (for System Presets) and Machine

view (for Machine Presets). For more information about System and

Machine Presets, see page 11.

systeM View

1:Single Stereo Config

(System View)

Current Preset

Clock Sync icon

Configuration Icon

Clock Rate

MaChine View

0:Large Hall

1:PreDelay :20ms

2:ReverbTime :2.79s

3:RvbOutFreq :6500.0Hz

Current Preset

Configuration Icon

Soft Row Parameters

Clock Sync icon

Clock Rate
