seleCting yoUr aUdio soUrCe and CloCk soUrCe

1. Press the Machine button until the words “System View” appear in the

Display.

1:ConcertHall->Flange

(System View)

1:Single Stereo Config

(System View)

2. Press the Select knob. The System Menu appears.

System Menu Version 1.0

+Audio Setup

Machine Config

MIDI Control

3. With Audio Setup highlighted, press the Select knob. The Audio Setup

menu appears.

|:Audio Setup

Audio Source: ANALOG A

Clock Source: INTERNAL B

Clock Rate: 48KHz (Lock) C

4. Turn Knob A to select your audio source (Analog or AES).

5. Turn Knob B to select your wordclock source (Internal, AES, or BNC).

6. Press the Back button twice to save your changes and return to the

Preset screen.

loading a Preset

1. From the Preset screen, turn the Select knob to scroll through the avail-

able presets in the current category. (Presets are arranged in categories

within the PCM96 Surround; see Changing Categories below for more

information.) The preset name blinks after you turn the Select knob,

indicating that you are in preset selection mode.

2. Press the Select knob to load the preset you’ve selected. The display

briefly reads Loading Preset, and the preset name appears. It is no longer

blinking.

Changing Categories

Presets are grouped into categories in the PCM96 Surround. Each category

has its own set of presets. When you turn the Select knob while viewing a

preset, you only see presets available in the current category.

System Presets and Machine Presets each have their own set of categories.

System Preset categories are based on DSP configurations (see page 16), and

Machine Preset categories are based on algorithms (see page 37).
