CasCade stereo

The left and right signals are processed together in one virtual

machine, and the resulting signal is sent to a second virtual

machine, where they are again processed together.

dUal Mono

The left signal travels through one virtual machine, and the

right signal travels through a separate second virtual machine.

QUad Mono

Four mono signals are processed independently by four vir-

tual machines.

CasCade Mono

The left signal is sent through two virtual machines in

sequence, while the right signal is sent through two additional

virtual machines in sequence. The left and right signals are

processed independent from each other.

dUal Mono + single stereo

Two mono signals are processed independently by two virtual

machines, while a stereo signal is processed by a third virtual

machine.

CasCade Mono to stereo

The left and right signals are processed independently in two

separate virtual machines, and their resulting signals are pro-

cessed together in a third virtual machine. The final result is

output as stereo.

single two in foUr oUt

Two signals are processed by one virtual machine, and output

as four signals.

single foUr in foUr oUt

Four signals are processed by one virtual machine, and output

as four signals.
