Important Safety Instructions
1. READ INSTRUCTIONS
All the safety and operating instructions should be read before
the appliance is operated.
2. RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for
future reference.
3. HEED WARNINGS
All warning on the appliance and in the operating instructions
should be adhered to.
4. FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5. WATER AND MOISTURE
The appliance should not be used near water – for example,
near a bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool, etc.
6. CARTS AND STANDS
The appliance should be used only with
a cart or stand that is recommended by
the manufacturer.
6A. An appliance and cart combination
should be moved with care. Quick
stops, excessive force, and uneven
surfaces may cause the appliance and
cart combination to overturn.
7. WALL OR CEILING MOUNTING
This equipment is not designed for use mounted on a wall or a
ceiling.
8. VENTILATION
The appliance should be situated so that its location or
position does not interfere with its proper ventilation. For
example, the appliance should not be situated on a bed, sofa,
rug, or similar surface that may block the ventilation openings,
or places in a built-in installation, such as bookcase or cabinet
that may impede the flow of air through the ventilation
openings.
At least 30 cm free space around the unit for normal
ventilation is required.
9. HEAT
Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
10. CLEANING
The appliance should be cleaned only with dry cloth.
11. POWER SOURCES
The appliance should be connected to a power supply only of
the type described in the operating instructions or as marked
on the appliance.
12. POWER CORD PROTECTION
Power-supply cord should be routed so that they are not likely
to be walked on or pinched by items placed upon or against
them, playing particular attention to cords at plugs,
convenience receptacles, and the point where they exit from
the appliance.
13. POLARIZED PLUG
Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. When the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete
outlet.
14. UNPLUG POWER CORD
Unplug this apparatus during lightning storms or when unused
for long periods of time.
15. OBJECT AND LIQUID ENTRY
No object filled with liquids, such as vases, etc. shall be placed
on the apparatus.
16. ACCESSORIES
Only use attachments/accessories specified by the
manufacturer.
17. SERVICING
The user should not attempt to service the appliance beyond
that described in the operating instructions. All other servicing
should be referred to qualified service personnel.
18. DAMAGE REQUIRING SERVICE
The appliance should be serviced by qualified service
personnel when:
a) The power-supply cord or the plug has been damaged; or
b) Objects have fallen, or liquid has been spilled into the
appliance; or
c) The appliance has been exposed to rain; or
d) The appliance does not appear to operate normally or
exhibits a marked change in performance; or
e) The appliance has been dropped, or the enclosure is
damaged.
