AMERICAN DJ Focus Spot ONE [16/18] Unscrew the single screw 2 flip the top cover back

ADJ Products, LLC - www.adj.com - Focus Spot One Instruction Manual Page 30 ADJ Products, LLC - www.adj.com - Focus Spot One Instruction Manual Page 31

Focus Spot One Removing the Head Casing

rew

1. Unscrew the single screw 2. Flip the top cover back

3. Remove the lens

4. Unscrew the 4 screws

located on the other side

Focus Spot One Dimmer Curve Chart

(Fade Time) (Fade Time)

Ramp Effect

Standard

Stage

Architectural

Theatre

Focus Spot One Photometric Chart

Distance(m)

1 Lux6°

22510 5448 2525 1424W

Diameter(m)16°

0.281

0.562

0.843

1 405.

935

1.24

16°
