Nec NP03WK [12/14] Adjust the horizontal tilt of the projector

Turn the left or right knob to adjust projector tilt in the

left or right direction.

- When the knob shown in black in the illustration

counterclockwise direction.

When the adjustment is complete, tighten the opposite

3. Adjust the horizontal tilt of the pr

ojector.

The projector adapter allows adjustment over a range of approximately ±3 degrees.

Loosen the horizontal fixation nut (double nut) with a wrench.

Loosen the horizontal adjust screws (left and right) with the supplied hex wrench.

- Loosen the two screws shown in black in the illustration.

Make the adjustment by tightening the left or right screw until the top edge and bottom edge

of the image are parallel.

When the adjustment is complete, tighten the opposite screw that is still loosened.

Tighten the horizontal fixation nut (double nut) with a wrench.

is ti ghtened, the projector is rotated in the

knob that is still loosened.
