Nec NP03WK [8/14] Mounting the projector

Align the projector adapter with the holes on the bottom of the projector and securely attach

the adapter with the four supplied screws (M4x20).

Loosen the vertical adjust/arm fixation knobs of the pr

ojector adapter.

Vertical adjust/arm fixation knobs

Warning

are used, the projector may be seriously

damaged, or the projector may fall and

cause injury. Be sure to use only the

supplied screws.

2. Attach the wall adapter to the structural material of the wall.

To ensure a projected image without distortion, the center of the wall adapter and the center of

the screen should be aligned on a straight axis.

• The wall adapter has a top/bottom orientation. Be sure to attach it with correct orientation.

Caution

If the wall adapter is mounted with reversed top/bottom orientation, correct

installation is not possible.

• The wall adapter can be adjusted horizontally over a range of ±50mm.

Side with cutouts facing up

Side without cutouts facing down

Warning

If screws other than the supplied ones

Mounting the Projector

Use only M6 (1/4 inch) screws

or bolts (4 locations) to fix the wall

adapter. If screws or bolts other than M6

are used, the pr

ojector may fall and

cause injury.

the installation position of the wall mount unit.

1. Determine the installation location of the screen, and accordingly decide

Refer to the section "Installation" in the user’s manual included with the projector for more

information.

• Installation for slanted projection is not possible. Determine the position for frontprojection.

on page 2 of this manual are met.

• Because the M260XS/M300XS/M350XS/M260WS/M300WS have a large optical axis

elevation angle, a slight shift in projection distance will have a large effect on the screen

size and position. If the projector angle is off, image distortion will increase.

Preparations

2. Make sure that all conditions described in the section "Heed the Following"
