Nec NP03WK [14/14] Specifcations

. retpada llaw eht dna retpada rotcejorp eht ot srevoc eht hcattA

. retpada llaw eht fo edis reppu eht ot )hcton htiw( )B( revoc dna )kooh htiw( )A( revoc hcattA

Slide the two coverstowards the center while pushing them down, as shown in the

illustration. The bottom of each cover will then engage with the screw heads of the wall

adapter. At the same time, the hook of cover (A) will enter the notch of cover (B), thereby

locking the covers.

On the bottom side of the wall adapter, reverse the positions of covers (A) and (B) and attach

them in the same way as described in

.revoc mra eht hcattA

The cover is fixed when the left and right tabs engage with the notches on the projector

adapter.

Notch

Hook

Cover (A)

Cover (B)

Cover (A) should be at right

Cover (B) should be at left

Arm cover

Wall mount unit

Adjustment angle: Up-down angle ±3°, left-right angle

±3°

, inclination angle

±10°

Adjustment width: Front-rear ±180 mm, left-right ±50 mm, up-down ±50 mm

NP02WK External dimensions: 280 (W) x 885 (D) x 219 (H) mm

NP02WK Weight: Approx.7.5 kg

•Specifcations and design are subject to change without notice.

Specifcations

Product name:

M000007-100012810

2011.03.01 rev. A02

NP03WK External dimensions: 280 (W) x 1160 (D) x 219 (H) mm

NP03WK Weight: Approx.

10.5 kg

NP02WK/NP03WKModel:
