7
EN
c) Do not recharging non-rechargeable batteries!
d) During charging, batteries must be placed in
the well ventilated area!
Residual risks
Even when the power tool is used as
prescribed it is not possible to eliminate all
residual risk factors. The following hazards
may arise in connection with the power tool’s
construction and design:
a) Health defects resulting from vibration
emission if the power tool is being used
over longer period of time or not adequately
managed and properly maintained.
b) Injuries and damage to property to due to
broken accessories that are suddenly dashed.
Warning! This power tool produces an
electromagnetic field during operation.
This field may under some
circumstances interfere with active or
passive medical implants. To reduce the
risk of serious or fatal injury, we
recommend persons with medical
implants to consult their physician and
the medical implant manufacturer before
operating this power tool.
2. MACHINE INFORMATION
Intended use
This cordless drill is intended for driving in and
loosening screws as well as for drilling in wood,
metal and plastic.
Technical specifications
Model No CDM1168
Voltage 20V
Chuck capacity 0.8 - 10mm
Torque settings 17 + Drill mode
Hard (Stall) torque 50Nm
No load speed
Position 1: 0-450 /min
Position 2: 0-1600 /min
Sound pressure level L
PA
75.3 dB(A), K=5dB(A)
Sound power level L
WA
83.6 dB(A), K=5dB(A)
Vibration 2.68m/s
2
k=1.5m/s
2
Model No CDA1159
Battery Type Lithium-Ion
Voltage 20V
Capacity 2.0 Ah
Recommended charger
CDA1161, CDA1162,
CDA1173
Weight 0.3 kg
Model No CDA1173
Charger input
220-240V ~ 50/60Hz
Max 1.2A
Charger output 21.5
1.8A
Rechargeable battery pack 20V Li-ion 1.5Ah
Charging time 2.0Ah battery 80 minutes
Charging time 4.0Ah battery 160 minutes
Recomended batteries CDA1159, CDA1160
Weigth 0.15 kg
Only use the following batteries of the FX-POWER
20V battery platform. Using any other batteries
could cause serious injury or damage the tool.
CDA1159 20V, 2Ah Lithium-Ion (Included)
CDA1160 20V, 4Ah Lithium-Ion
The following charger of the can be used to
charge these batteries.
CDA1161 Charger adapter
CDA1162 Quick charger
CDA1173 Charger base (Included)
The batteries of the FX-POWER 20V battery
platform are interchangeable with all the FERM
FX-POWER battery platform tools.
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardized test given in
EN 62841; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned.
• Using the tool for different applications, or with
different or poorly maintained accessories,
may significantly increase the exposure level.
•
The times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level.
