Hisense U5120G [13/19] Basic operation
![Hisense U5120G [13/19] Basic operation](/views2/2017204/page13/bgd.png)
13
device) around your location. Remove these
conicts or strong interferences and repeat the
above procedures.
• The subwoofer should be within 6m (18 feet)
of the soundbar in an open area.
• If the main unit is not connected with the
subwoofer and it is in On mode, the POWER
Indicator will ash. Follow step 1 ~ 4 above to
pair the subwoofer to the main unit.
Use the Hisense EzPlay Function
For Hisense EzPlay, when the Soundbar connects
with a Hisense TV via HDMI ARC, therr will be a
Soundbar Setting menu on the TV, and you can
control this menu via you TV remote to control
most of the Soundbar features.
TV menu example (different models may have
dierent menus) :
Setting--sound--Soundbar Setting.
Note:
• This function is available only when both
Soundbar and TV support Hisense Ezplay.
• This function requires Soundbar and TV
connected via HDMI ARC, and the CEC of the
TV must be trned ON.
• If everting setting right, for the first time
connect, there would be a tip on the TV screen
to guide you nd the Soundbar setting menu.
Basic Operation
Standby/ON
When you rst connect the main unit to the mains
socket, the main unit will be in Standby mode.
• Press the button on the unit or on the
remote control to switch the unit ON.
• Press the button again to switch the unit
back to STANDBY mode.
• Disconnect the mains plug from the mains
socket if you want to switch the unit OFF
completely.
Auto-Standby / Auto-Wake Feature
• [Auto-Standby] Your soundbar has been
programmed to enter Standby mode
automatically when no audio is detected for
15 minutes. For example, this would happen
when pausing playback, or should the
soundbar be left on accidentally.
• [Auto-Wake] If a TV or an external device is
connected (COAXIAL/OPTICAL socket), the unit
will switch on automatically when the TV or
the external device is switched on.
To disable this feature, please follow the steps
below:
1. During ON mode, pointing the remote at the
soundbar, press and hold the button for 3
seconds to open the menu.
- The unit’s display will scroll “MENU”.
2. Press the button 6 times in succession
：
the display shows: AutoWake [ON / OFF].
or
Press the button 7 times in succession, the
display shows: AutoStandby [ON / OFF].
3. Select the content with VOL +/- button on the
remote control, and then press to confirm
your selection and exit the settings.
• Repeating these steps will toggle the feature
"ON" and "OFF".
Select Modes
• Press the (SOURCE) button repeatedly on
the unit or on the remote control to select the
OPTICAL, COAXIAL, HDMI 1, HDMI 2, HDMI ARC,
USB and BT (Bluetooth) mode.
• Press the button on the remote control to
select the BT (Bluetooth) mode.
