14
• The selected mode will show on the display.
Display Mode
ARC
HDMI IN 1
HDMI IN 2
OPTICAL
COAXIAL
Bluetooth
Connected
Connection
USB
Adjust the Bass/Treble Level
• Press the BASS +/- buttons on the remote
control to adjust bass level (bass +5 / bass -5).
• Press the TREBLE +/- buttons on the remote
control to adjust treble level (treble +5 / treble -5).
Turn the Surround Sound ON/OFF
• Press the SURR button on the remote control
to turn on the surround sound. Press this
button again to turn o the surround sound.
Adjust the Volume
• Press the VOL+ / VOL- buttons on the unit or
on the remote control to adjust the volume.
• If you wish to turn the sound o, press the
(MUTE) button on the remote control. Press
the (MUTE) button again or press the VOL+
/ VOL- buttons to resume normal listening.
Adjust the Brightness
- Press the DIMMER +/- button on the remote
control to select brightness level.
Select Equalizer (EQ) Eect
• While playing, press the EQ button on the
remote control to select desired preset
equalizers: MUSIC, MOVIE, NEWS, SPORT,
NIGHT, GAME, AI EQ.
Set the Audio Delay (AV SYNC)
• Video image processing, sometimes longer
than the time required to process the audio
signal. This is called “delayed.” Audio Delay
feature is designed to remedy this delay.
• Set the audio delay, provided only for the
current playback mode. (As provided in the
HDMI ARC audio delay mode, the delay mode
is valid only for the HDMI ARC).
- By default, the audio delay is set to 00.
1. During ON mode, press and hold the
button for 3 seconds to open the menu, then
press the button 9 times in succession. The
unit’s display will scroll “ LT 00”.
2. Press the VOL+/- buttons will be a 10 ms
frequency hopping to adjust the delay time.
Set 200 ms maximum delay.
3. Press the
button or exit settings 10S.
Tip:
• Adjustment range: [00~200ms]
• The audio delay setting is only valid for digital
audio (eg HDMI IN, HDMI ARC, COAXIAL,
OPTICAL).
DTS: X Operation
Neural:X / Virual:X / DRC / Dialog
Control Feature
DTS:X® and DTS® Virtual:X™ technologies provide
users with virtual multi-channel virtual surround
eects, creating an immersive audio volume.
- During ON mode, pointing the remote at the
soundbar, press and hold the button for 3
seconds to open the menu.
- The unit’s display will scroll “MENU”.
Neural:X / Virual:X Setting:
1. Press the button 11 times in succession
：
the display shows: Dts Neural [ON / OFF].
2. Press the button 12 times in succession,
the display shows: Dts Virual [ON / OFF].
DRC Setting:
• Press the button 13 times in succession,
the display shows: Dts Drc Heavy / Dts Drc
Mid / Dts Drc Min.
Adjust the Dialog Control:
• Press the button 14 times in succession,
the display shows: Dts Dialog Control 0~6
- Select the content with VOL +/- buttons on the
remote control, and then press to conrm
your selection and exit the settings.
- Repeating these steps will toggle the feature
ON and OFF.
